XNCLH26M000THJA2P0,Murata村田晶振,XNCLH有源振荡器

频率：26 MHz

尺寸：5.00mm x 3.20mm

Original model 原厂编码	XNCLH26M000THJA2P0
Manufacturer 品牌	Murata村田晶振
Part Series 型号	XNCLH
Type 类型	TCXO
Frequency 频率	26 MHz
Output Type 输出方式	削峰正弦波
Supply Voltage 电压	3V
Frequency Stability 频率稳定性	±200ppb
Operating Temperature 工作温度	-40°C ~ 85°C
Current Consumption 电流消耗	2.6mA
Package Size 包装尺寸	5.00mm x 3.20mm

订购热线：13380314981

XNCLH26M000THJA2P0,Murata村田晶振,XNCLH有源振荡器详细参数

Original model 原厂编码	XNCLH26M000THJA2P0
Manufacturer 品牌	Murata村田晶振
Part Series 型号	XNCLH
Type 类型	TCXO
Frequency 频率	26 MHz
Output Type 输出方式	削峰正弦波晶振
Supply Voltage 电压	3V
Frequency Stability 频率稳定性	±200ppb
Operating Temperature 工作温度	-40°C ~ 85°C
Current Consumption 电流消耗	2.6mA
Package Size 包装尺寸	5.00mm x 3.20mm
Package Height 厚度	1.50mm
Termination 脚位	8Pad
Package Type 封装类型	8-SMD
Lead Free 无铅	Yes
Mounting Style 安装方式	Surface Mount
Packaging 包装	Tape and Reel
