ELVTX-11-A-26.000MHz-A10-T,AEL艾尔晶振,ELVTX-11有源差分晶振

频率：26.000MHz

尺寸：3.20mm x 2.50mm

Original model 原厂编码	ELVTX-11-A-26.000MHz-A10-T
Manufacturer 品牌	AEL有源晶振
Part Series 型号	ELVTX-11
Type 类型	VCTCXO
Frequency 频率	26.000MHz
Output Type 输出方式	削峰正弦波输出晶振
Supply Voltage 电压	3.0V
Frequency Stability 频率稳定性	±1.0ppm
Operating Temperature 工作温度	0°C ~ +70°C
Package Size 包装尺寸	3.2mm x 2.5mm

订购热线：13380314981

ELVTX-11-A-26.000MHz-A10-T,AEL艾尔晶振,ELVTX-11有源差分晶振详细参数

Original model 原厂编码	ELVTX-11-A-26.000MHz-A10-T
Manufacturer 品牌	AEL有源晶振
Part Series 型号	ELVTX-11
Type 类型	VCTCXO
Frequency 频率	26.000MHz
Output Type 输出方式	Clipped Sine Wave
Supply Voltage 电压	3.0V
Frequency Stability 频率稳定性	±1.0ppm
Operating Temperature 工作温度	0°C ~ +70°C
Package Size 包装尺寸	3.2mm x 2.5mm
Package Height 厚度	1.2mm
Termination 脚位	4-pad
Package Type 封装类型	4-SMD
Lead Free 无铅	Yes
Mounting Style 安装方式	Surface Mount
Packaging 包装	Tape and Reel
